Case Making Machine EB - 75
Case making machine Mark - Easy Bind 75 is automation to the conventional manual case making process. Easy bind 75 ensures high productivity, superior & uniform case quality throughout the job run. It is redefining case making process in post press. Easy Bind is designed and developed with special concern on higher productivity, simple operation, large variety of jobs, ease of maintenance & most suitable size for binding.
Applications : Case making for hard bound books, diaries, files, registers, notebooks, calendars, clip boards etc. Back to back pasting & pressing for duplex boards, pharmaceutical catalogs and other packaging items.
Case Making Machine EB - 75 Salient Features
- Automatic glue tank temperature control with auto cut off for optimum power use
- Sheet counter
- Uniform thickness of glue layer on title sheet with easy adjust control
- Easy mounting & dismounting of glue tank
- Multiple glue tank for different glue (optional)
- Precise title and Spine (board) gauging unit up to 4 spines
- Easy and rapidly adjustable gauging system
- Vacuum table and vacuum blower for easy handling of thin sheets
- Short make ready time (Approx. 20 mins for hot glue, immediate for cold glue)
- Less than 5 minutes for size changes
- PLC program cycle for case making and back to back pasting
- Dual speed for turning system, fast and medium speed cycles
- Long lasting, high quality PU conveyor belt
- Roller turning device for thin board (optional)
Case Making Machine EB - 75 Applications:
- Case making machine for hard bound books
- Case making machien for diary
- Case making machine for files
- Case making machine for register
- Case making machine for notebook
- Case making machine for calendar
- Case making machine for clip board, exam pad
- Case making machine for pharmaceutical catalog
Case Making Machine EB - 75 : Semi Automatic Case Maker
PRODUCTS
Case Making Machine EB - 75 Video 1
Case Making Machine EB - 75 Video 2
© 2013 All rights reserved.
Mark Engineering Address: L-133, G.I.D.C Estate, Odhav, Ahmedabad - 382415. Gujarat (India)
Website: www.markengineering.in Parimal Varma +91-9427007053, parimal@markengineering.in, Vasant Varma +91-9426303910, vasant@markengineering.in
Case Making Machine Technical Details
Case Making Machine EB - 75 Video 3
Case Making Machine EB - 75 Video 4
Case Making Machine SCM - 55
Mark case making machine SCM - 55 is automation to the conventional manual case making process. SCM - 55 ensures high productivity, superior & uniform case quality throughout the job run. SCM - 55 is designed and developed with special concern on consistent quality, simple operation, large variety of jobs, ease of maintenance & most suitable size for binding. SCM 55 has automatic board gauge up-down system to keep operator handsfree. It has amazingly short new job setup time of less than 5 minutes.
Applications : Case making for hard bound books, diaries, files, registers, notebooks, calendars, clip boards etc. Back to back pasting & pressing for duplex boards, pharmaceutical catalogs and other packaging items.
Case Making Machine SCM - 55 Salient Features
- Automatic glue tank temperature control with auto cut off for optimum power saving
- Digital counter
- Uniform thickness of glue layer on title sheet with easy adjust control
- Easy mounting & dismounting of glue tank
- Multiple glue tank for different glue (optional)
- Pneumatic on off for spine board gauges
- Vacuum table and vacuum blower for easy handling of thin sheets
- Precise title and Spine (board) gauging unit up to 4 spines
- Easy and rapidly adjustable gauging system
- Short make ready time (Approx. 20 mins for hot glue, immediate for cold glue)
- Less than 5 minutes for size changes
- 100 Micron thick hard chrome plated roller/ Stainless Steel rollers (Optional)
- Best quality control panel components used to make machine most reliable.
Case Making Machine SCM - 55 Applications:
- Case making machine for hard bound books
- Case making machine for diary
- Case making machine for files
- Case making machine for register
- Case making machine for notebook
- Case making machine for calendar
- Case making machine for clip board, exam pad
- Case making machine for pharmaceutical catalog
Case Making Machine SCM - 55: Semi Automatic Case Maker
TECHNICAL DATA (mm)
|
CASE MAKER SCM 55
|
Min. case size
|
150 mm x 150 mm
|
Max. case size
|
500 mm x 750 mm
|
Paper thickness
|
70 gsm To 170 gsm
|
Board thickness
|
0.5 mm To 5 mm
|
Turning in width
|
15 To 25 mm
|
Speed*
|
200 case/hr depending upon case size, material
|
Glue type
|
Hot / Cold
|
Pneumatic pressure
|
6 - 8 bar
|
Power
|
2 HP for 2 AC variable speed motors, 2 kW for heater
|
Materials
|
Paper, laminated, paper, plastic coated paper, cloth
|
Floor space**
|
1200 mm (L) x 2800 mm (W) x 1500 mm (H)
|
1 HP air compressor
|
to be provided by client
|
Case Making Machine SCM - 55 Video 1
Case Making Machine Technical Details
Case Making Machine SCM - 55 Video 2
TECHNICAL DATA (mm)
|
CASE BIDING MACHINE EB 75
|
CASE BIDING MACHINE EB 105
|
Min. case size
|
150 mm x 150 mm
|
150 mm x 150 mm
|
Max. case size
|
750 mm x 750 mm
|
1050 mm x 1050 mm
|
Paper thickness
|
70 gsm To 170 gsm
|
70 gsm To 170 gsm
|
Board thickness
|
0.5 mm To 5 mm
|
0.5 mm To 5 mm
|
Turning in width
|
15 To 25 mm
|
15 To 25 mm
|
Speed*
|
300 case/hr depending upon case size, material
|
300 case/hr depending upon case size, material
|
Glue type
|
Hot / Cold
|
Hot / Cold
|
Pneumatic pressure
|
6 - 8 bar
|
6 - 8 bar
|
Power
|
3.5 HP for 2 AC motors, 3 kW for heater
|
3.5 HP for 2 AC motors, 4 kW for heater
|
Materials
|
Paper, laminated, paper, plastic coated paper, cloth
|
Paper, laminated, paper, plastic coated paper, cloth
|
Floor space**
|
1200 mm (L) x 3600 mm (W) x 1500 mm (H)
|
1500 mm (L) x 3600 mm (W) x 1500 mm (H)
|
1 HP air compressor
|
to be provided by client
|
to be provided by client
|
